Ampatop Reflecto WS
Neu
Reflective wall membrane
Reflective wall membrane.
- Reflective foiled membrane increases thermal performance of structure
- Breathable vapour open wall membrane
- Cutting and orientation aid
- Breathable membrane reducing the risk of condensation
Triple layer reflective external breathable wall membrane.
Conditions for the twenty-year premium warranty include registering the building object and the Ampack products used. In addition, our products must be used as part of a system. For further details, please see our General Warranty Conditions.
| Article number | Description | Roll dimensions |
|---|---|---|
7640115537683 | Ampatop Reflecto WS | 2,7 m × 100 m = 270 m2 |
7640115537669 | Ampatop Reflecto WS | 3,0 m × 100 m = 300 m2 |
| Property | Value | Standard |
|---|---|---|
| Harmonised European Standard | EN 13859-2:2014 | |
|
Mass per unit area |
140g/m2 |
EN 1849-2 |
|
Fire behaviour |
E | EN 13 501-1 / EN ISO 11925-2 |
|
Resistance to water penetration |
W2 | EN 1928, procedure A |
|
Water vapour permeability, sD value |
0,11 m | EN 1931 |
|
Temperature resistance |
-40 bis +80 °C | |
|
Maximum tensile strength longitudinal / transverse |
260 / 200 N/5 cm |
EN 12 311-2, without support liner EN 13 859-1, Appendix A, with support liner |
|
Resistance to tearing (nail) longitudinal / transverse |
150 / 150 N |
EN 12 310-1 without support liner EN 13 859-1, Appendix B, with support liner |
|
Cold bending behaviour (flexibility) |
-40 °C | EN 1109 |
|
Outdoor weathering |
3 months | |
| Visible defects | none | EN 1850-2 |
| Values after artificial ageing | ||
|
Maximum tensile strength longitudinal / transverse |
260 / 200 N/5 cm |
EN 13859-1, appendix C, EN 1297, EN 1296 |
|
Elongation longitudinal / transverse |
260 / 200 N/5 cm |
EN 13859-1, appendix C, EN 1297, EN 1296 |
|
Resistance to water penetration |
W2 | EN 1928 |
